Description
- The instrument should be designed and made as per T 0623 and ASTM D88 Bitumen Saybolt Viscosity Test (Saybolt Viscometer Method) in the JT3052 Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering.
- It is suitable to determine the Saybolt viscosity of bitumen and bituminous mixtures under a constant temperature as per 10623.
Features:
- This instrument should be composed of bath, temperature controller, parameters display and calculation (calibration coefficient, time, viscosity and so on)
- This instrument should adopt micro computer technology. It equips double lines to detect. It can determine two samples at the same It can display the parameters and calculate the arithmetic mean value automatically.
- This instrument can convert the Saybolt viscosity to Engler viscosity and kinematic viscosity automatically. Operator can get three viscosity data from one The work efficiency is high.
Specifications:
- Power supply: AC (220±10%)V, 50Hz
- Instrument structure: Desk type
- Working mode: Double lines, parallel test
- Receiving flask: (60±0.05) ml
- Heating power of bath: 1000W
- Working temperature of bath: Room -240.0°C
- Temperature control accuracy: ±0.1°C
- Timing range: 05-999.9%
- Timing accuracy: ±0.15
- Ambient temperature: $35°C
- Relative humidity: 585%. All Excessories Extra set Should be
- Overall dimension: 360mm x 360mm x 790mm
