Description
Technical Parameter:
– Idea for electrical circuit experiment and designing exercises.
– Scope of Learning
– Show skill in verification of Ohm’s Law.
– Verify the characteristics of series circuits.
– Verify the characteristics of parallel circuits.
– Verify the characteristics of mixed circuits.
– Show skill in measuring the power of an electric circuit.
– Show skill in grouping a number of cells to form a battery.
– Show skill in verifying kerchief’s Current law.
– Show skill in verifying kerchief’s Voltage law.
– Show skill in verifying Thevenin’s theorem.
– Show skill in verifying Norton’s theorem.
– Show skill in verifying Nodals’s theorem.
– Show skill in verifying Superpostion theorem.
– Show skill in verifying Maxwell theorem.
– Show skill in maximum power transfer theorem.
– Transformer Open Circuit Test
– Transformer Short Circuit Test
– Parallel Operation of Transformer
– Regulation Test of Transformer.
Specification:
– Digital Watt meter: 2 EA (0-6000W)
– Analog AC Voltmeter: 3 EA(0-500V)
– Digital DC Voltmeter: 1 EA(0-500V)
– Digital AC Ammeter: 2 EA(0-5A)
– Digital DC Ammeter: 1 EA(0-5A)
– AC Power Supply (0~250VAC,50Hz): 10 EA (Min)
– DC power supply unit (0,6,12,18,24,30,36V±10%,10 Amp): 10 EA
– Resistive Load (550Ω, 1100 Ω, 1600 Ω ±10%,200W): 3 EA (Min)
– Inductive Load (1h,2h,3h, ±10%,): 3 EA(Min)
– Capacitive load (1.5uF,3uF,4.5uF, ±10%,): 3 EA (Min)
– fan cooling system: 6 EA (Min)
– Permanent magnet DC motor /Generator Set: 1EA (Min)
– 1 set DC generator Prime Mover: 1 EA (Min)
– External AC connection facility
– 2 Training Manual
– 4mm safety banana socket
– Size (L x W x H) = (60?x36?x12?)
– Weight: 60Kg (Approx)
– Power requirements: 220~240V AC, 50Hz
– Built-in short circuit protection system.
Accessories:
– Experiment Manual: 02 Set
– Connecting Cord: 03 Set
– Power Cord: 02 No
Safety & Security: Over voltage, over current and earth fault protection must be ensured for the above-mentioned Pole Changing Module.
– Warranty: 2 years
