Description
- The instruenent should be designed and made standard GB/T 4929 Lubricating grease- Determination of Dropping Point and ASTM D566 Standard Test Method for Dropping Point of Lubricating Grease.
Features:
- The oil bath should be composed of heat resistant beaker, heater and electric
- The heating power can be adjusted continuously. The temperature in oil bath is
- Should have desktop structure
- Should be Easy to Specifications:
- Power Supply: AC (220±10%)V,
- Total Consumption:
- Oil Bath: 600ml Beaker.
- Grease Cup: It should be made of chrome plated brass, inner diameter: 9.90mm, oil dripping hole: min. 2.8mm, cup height: min. 12mm.
- Test Tube: Heat resistant borosilicate glass tube with edge, inner diameter: 1 mm to 12.7 mm, and there are three grooves on the circumference 19 mm away from the bottom to support the grease cup.
- Thermometer: Temperature range: (5~300) “C; division value:
- Stirring mator: 60R/min.
- Working environment: Temperature: (15~35)°C Relative humidity: 585%.
- Dimension: 340mm×175mm×400mm.
- Net Weight: Skg. All Accessories Extra set Should be supplied.
