Description
- Standard: GB/T3536-2008; ASTM D92
- it is applicable to all petroleum products with flash points above 79°C and below 400°C except fuel oils.
Features:
- It should adopt technology of single chip microcomputer and LCD English man-machine interface. The heating device should be continuously adjustable. Easy set parameters.
- The LCD screen should have prompt menu, prompt type input for operation It should show set parameters and real-time display sample temperature and other parameters. Press the record key when flash point appearing. The screen should display and save flash point value.
- It should be a newly design and small Stainless steel working table make it elegant and beautiful. The operator can do determination as long as connecting with coal gas or other civil gas. Easy to use and results are exact.
- it should be equipped with wind-shelter and flame extinguishing cover which are accord with requirements of test.
- Accurate heating The instrument can do test automatically. Specifications:
- Power supply: AC (220±10%)V,
- Heating device: Electric furnace heating, no naked fire, explosion The power should be adjustable from OW to 600W. The max heating temperature can
reach 400°C
- Temperature control: Single chip The heating rate can meet requirements of standards GB/T 3536-2008 and ASTM D92.
- Temperature display: LCD should show temperature
- The display range should be 0°C-400°C, display accuracy should be 0.1°C.
- Flash point detecting device: It applies the test flame
- Temperature sensor: RTD, PT100
- Igniting device: (1) Ignition source: coal gas (or civil gas); (2) Flame diameter is 2mm 4.8mm
- Ambient temperature: (-10~50)°C
- Relative humidity: 585%
- Maximum power consumption: All Excessories Extra set Should be supplied.
- Dimension: 340mm×320mm×450mm (Temperature sensor is included)
